Aluminum color coils 5005 is widely used in aluminum-plastic panels, aluminum curtain walls, aluminum-magnesium-manganese roofing systems, aluminum ceilings and many other fields because of its light texture, bright color, easy processing and molding, no rust and other advantages.
Common specifications of aluminum color coils 5005
Temper: O, H44, etc
Thickness: 0.2mm-3.0mm
Width: 10mm-2000mm
Inner diameter: 405mm/505mm
Color: Standard color: including red, yellow, blue, green, white, gray and other basic colors and their derivatives; Metallic color: simulates metallic texture, such as silver gray, bronze, rose gold, etc.; wood grain, stone grain series; Mirrored, brushed, etc.
Coating thickness: Single coating 3-25μm, double coating 25-35μm, triple coating ＞35μm.
Standards: ASTM B209, GB/T 3880, EN AW, etc
Certification: CE, ISO, SGS, etc
Chemical Composition and Mechanical Property of aluminum color coils 5005
Chemical Composition
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti |
Others: Each |
Others: Total |
Al: Min. |
| 5005 | 0.30 | 0.70 | 0.20 | 0.20 | 0.5~1.1 | 0.1 | 0.25 | - | 0.05 | 0.15 | Remain |
Mechanical Property
| Alloy | State | Thickness(mm) | Tensile Strength(Mpa) | The Yield Strength(Mpa) | elongation(%) | hardness(HV) |
| 5005 | 0 | >0.2-0.5 | 100-145 | ≥35 | ≥15 | 33-43 |
| >0.5-1.0 | ≥20 | |||||
| >1.0-4.0 | ≥25 | |||||
| H22 | >0.2-0.5 | 125-165 | ≥80 | ≥12 | 30-53 | |
| >0.5-1.0 | ≥15 | |||||
| >1.0-4.0 | ≥18 | |||||
| H24 | >0.2-0.5 | 145-185 | ≥110 | ≥8 | 40-60 | |
| >0.5-1.0 | ≥10 | |||||
| >1.0-4.0 | ≥10 | |||||
| H26 | >0.2-0.5 | 165-205 | ≥135 | ≥3 | 50-68 | |
| >0.5-1.0 | ≥4 | |||||
| >1.0-4.0 | ≥6 | |||||
| H18 | >0.2-0.5 | ≥185 | ≥165 | ≥2 | 57-68 | |
| >0.5-1.0 | ≥2 | |||||
| >1.0-4.0 | ≥3 |
Paint classification of aluminum color coils 5005
The paint classification of aluminum color coils 5005 mainly includes polyester coating (PE) and fluorocarbon coating (PVDF). Each of these coatings has its own characteristics and application scenarios:
PE Paint
Features: The polyester coating can be firmly adhered to the surface of the aluminum plate, which has a protective and decorative effect. It is an anti-UV coating, which is colorful, shiny, smooth, and feels good, and can effectively protect objects from ultraviolet radiation, wind and rain, frost, snow and ice.
Application: suitable for interior decoration and advertising boards, etc.
PVDF
Features: Fluorocarbon coating has super acid resistance, alkali resistance, corrosion resistance and super yellowing resistance. Its paint texture is delicate, the color is uniform, the color is bright, and it is always new, especially suitable for large-scale outdoor, roof, curtain wall, ceiling and ceiling high-end decoration projects. Fluorocarbon coatings are suitable for harsh natural conditions, with high color durability, ultra-high flexibility and mechanical properties, and a much longer service life than polyester coatings.
Application: Mainly used for building exterior finishes, such as aluminum-plastic panels, aluminum curtain walls, etc.
The choice of these two coatings depends on the specific application needs and environmental conditions. Polyester coatings are suitable for applications where weather resistance and color retention are not very important, while fluorocarbon coatings are more suitable for applications that require extremely high weather resistance and durability.
Of course, there are also cases where one side is coated with fluorocarbon and the other side is coated with polyester; There are even cases where both sides are coated with fluorocarbon. Customized according to customer needs. There are also highly weather-resistant polyester and scratch-resistant paints.
Paint brand of aluminum color coils 5005
Commonly used paint brands for aluminum color coils 5005 include:
1: AkzoNobel, an international chemical company with a long history, offers a wide range of high-quality paints and coatings.
2: PPG, a well-known brand of advanced coatings, paints and special materials in the world.
3: The Beckers Group has a history of more than 150 years and is headquartered in Sweden. Berg's product range includes coil coatings, specialty coatings and wood surface coatings. Berger is also one of the world's leading suppliers of major art pigments.
Application of aluminum color coils 5005
Aluminum color coils 5005 is mainly used in the fields of building decoration, food packaging, electronic appliances, printing and transportation. The specific applications are as follows:
Architectural decoration
Color-coated aluminum coils can be used to manufacture roof panels, roof panels, curtain wall panels, interior wall decorative panels, ceiling ceiling panels, honeycomb panels, thermal insulation panels, roller shutter doors, shutters, etc.
Food packaging:
Aluminum color coils 5005 suitable for the manufacture of pressure-free food cans, pressure food cans, can caps, bottle caps, box lids, pull rings, food boxes, all kinds of food packaging sealed bags, etc.
Electronic appliances
used in the manufacture of air conditioning panels, washing machine panels, refrigerator panels, cabinet panels, and various digital electronic product shells.
Printing
It is suitable for manufacturing PS, CTP, UV-CTP printing plates.
Transportation
It can be used to manufacture box truck shells and inner walls, car body panels, train compartment panels, ship interior panels, transportation facility signs, advertising display boards, luggage, etc.
Color coated aluminum coil 5005 has a wide range of applications in many fields due to its good decoration, weather resistance, mechanical and environmental protection, and can meet the needs of use in different environments.
Worthwill's aluminum color coils 5005
Worthwill provide high-quality aluminum color coils 5005 at competitive prices. As the largest color-coated aluminum coil manufacturer in Henan, we have absolute advantages in quality, price, and delivery. The base material thickness ranges from 0.1-3.0mm, and the width ranges from 10-2000mm. The paint types include polyester, fluorocarbon, anti-scratch, etc. The colors are rich, from solid colors to metallic colors, from mirror to brushed, from wood grain to marble grain, and Various types of embossed products are available to meet your needs.
